Baileigh 5 Ton Arbor Press AP-5HD 1232701 Applications
- Bearing installation and removal operations.
- Riveting, staking, and fastening applications.
- Metal forming, bending, and straightening tasks.
- Punching and swaging operations.
- Assembly and production line manufacturing.
- Tool room and maintenance department work.
- Bushing, pin, and shaft installation.
- General fabrication and machine shop applications.
Ideal for workshops that require controlled manual pressing force, precise ram alignment, and durable construction for repetitive industrial operations.
Baileigh 5 Ton Arbor Press AP-5HD 1232701 Specifications
| Model Number | AP-5HD |
|---|---|
| Product Keyword | Baileigh 5 Ton Arbor Press AP-5HD 1232701 |
| Machine Type | Manual Arbor Press |
| Rated Capacity | 5 Tons |
| Input Power | Manual Operation |
| Throat Opening | 8.5 in. |
| Capacity Over Table | 17 in. |
| Maximum Material Height | Up to 18 in. |
| Stroke Length | 18 in. |
| Ram Size | 2 in. × 27.5 in. Solid Square Ram |
| Ram Construction | Case-Hardened Steel |
| Die Plate | Machined 4-Position Die Plate |
| Slideway Adjustment | Adjustable Tension and Gap |
| Frame Construction | Rigid Cast-Iron Frame |
| Mounting Options | Bench or Pedestal Mount |
| Net Weight | 350 lbs. |
| Gross Weight | 350 lbs. |
| UPC | 19907201120 |
| Warranty | 1 Year |
Baileigh 5 Ton Arbor Press AP-5HD 1232701 Performance & Construction
- 5-ton manual pressing capacity provides substantial force for assembly, fabrication, and maintenance applications.
- Rigid cast-iron frame construction minimizes flex and maintains precise alignment during heavy pressing operations.
- 2-inch solid case-hardened ram delivers exceptional durability and accurate force transfer to the workpiece.
- 8.5-inch throat opening provides ample access for larger components and difficult-to-reach work areas.
- 18-inch stroke length accommodates deep pressing operations and taller workpieces.
- Handles material up to 18 inches high for increased versatility across a wide range of applications.
- Machined 4-position die plate securely supports workpieces and simplifies setup for repetitive tasks.
- Adjustable slideway system allows fine-tuning of tension and clearance for smooth, precise ram movement.
- Precision-machined components ensure consistent performance and repeatable pressing accuracy.
- Manual operation provides complete operator control without requiring electrical or hydraulic power.
- Bench or pedestal mounting capability allows flexible installation based on shop layout and workflow requirements.
- Heavy-duty industrial design built to withstand years of demanding workshop and production use.
Why Choose the Baileigh 5 Ton Arbor Press AP-5HD 1232701
- Delivers 5 tons of controlled manual pressing force.
- Heavy cast-iron frame ensures long-term durability and alignment accuracy.
- Large 8.5-inch throat opening accommodates a variety of workpiece sizes.
- Case-hardened 2-inch ram provides reliable performance and extended service life.
- 18-inch stroke and generous work height increase application flexibility.
- Adjustable slideway and machined die plate improve precision and repeatability.
- Suitable for fabrication, assembly, maintenance, and production environments.
- Backed by Baileigh's 1-year parts warranty and lifetime technical support.
The Baileigh 5 Ton Arbor Press AP-5HD 1232701 combines industrial-strength construction, precise manual control, and versatile pressing capability to provide fabricators, machinists, and maintenance professionals with a dependable solution for pressing, forming, assembly, and repair operations.
