Gibraltar Machine Vise: Single-Station Swivel Base, Precision 110027 Applications
- Vertical and horizontal milling machine operations
- CNC machining centers requiring accurate workholding
- Precision drilling, tapping, boring, and reaming
- Tool rooms, maintenance departments, and machine shops
- Prototype manufacturing and production machining
- Fabrication shops performing angled machining operations
- General metalworking where repeatable positioning is critical
The 2-way angle design combined with a 360° swivel base allows operators to machine multiple surfaces without repeatedly removing and repositioning the workpiece, improving efficiency while maintaining machining accuracy.
Gibraltar Machine Vise: Single-Station Swivel Base, Precision 110027 Specifications
| Model Number | AMV;SP |
|---|---|
| Product Type | Single-Station Precision Machine Vise |
| Jaw Width | 4 in. (100 mm) |
| Jaw Height | 1.625 in. |
| Jaw Style | Steel V-Groove Jaws |
| Maximum Jaw Opening | 4 in. |
| Throat Depth | 1-5/8 in. |
| Operation Type | Manual |
| Orientation | 2-Way Angle (X & Y Axis Tilting) |
| Base Motion | 360° Swivel Base |
| Number of Stations | 1 |
| Vise Material | Heavy-Duty Cast Iron |
| Jaw Material | Steel |
| Base Length | 9.25 in. |
| Base Width | 6.38 in. |
| Base Height | 1.10 in. |
| Overall Length | 13.625 in. (345 mm) |
| Overall Width | 6.38 in. |
| Overall Height | 5.50 in. |
| Precision | Yes |
| Application | Machine Workholding |
| UNSPSC | 27112100 |
| Country of Origin | India |
Gibraltar Machine Vise: Single-Station Swivel Base, Precision 110027 Features & Performance
- Precision-machined construction delivers dependable accuracy and repeatable positioning for demanding machining operations.
- Heavy-duty cast iron body provides excellent rigidity while minimizing vibration during milling, drilling, and cutting.
- Hardened steel V-groove jaws securely grip both flat and round stock for versatile workholding capabilities.
- 4-inch jaw opening capacity accommodates a wide range of workpiece sizes used in fabrication and machine shop environments.
- 360-degree swivel base enables full rotation without removing the workpiece, reducing setup time and improving machining efficiency.
- 2-way angle positioning allows the vise to tilt around both the X and Y axes for complex angled machining operations.
- Manual operation offers smooth, controlled clamping with reliable holding power for precision work.
- Single-station design maximizes rigidity while providing stable support for precision machining applications.
- Precision throat depth and jaw geometry provide excellent accessibility while maintaining strong clamping performance.
- Designed for machine tool use including milling machines, machining centers, drill presses, and other precision metalworking equipment.
Why Choose the Gibraltar Machine Vise: Single-Station Swivel Base, Precision 110027
- Precision manual machine vise built for professional machining applications.
- 360° swivel base improves workflow without repositioning the workpiece.
- 2-way angle capability supports complex multi-angle machining operations.
- Heavy-duty cast iron construction provides long service life and machining stability.
- Steel V-groove jaws securely hold both flat and cylindrical materials.
- Excellent choice for CNC machining, milling, drilling, fabrication, and tool room work.
California Proposition 65 Warning: This product contains Nickel, a chemical known to the State of California to cause cancer. For more information, visit www.P65Warnings.ca.gov.
