Gibraltar Machine Vise: Single-Station Stationary Base 428-72682 Applications
- Vertical and horizontal milling machine operations
- CNC machining centers
- Drilling, tapping, boring, and reaming
- General-purpose machine shop work
- Production machining and fabrication
- Maintenance and repair facilities
- Toolrooms and manufacturing environments
- Machining straight surfaces requiring rigid workholding
The stationary base allows the vise to be mounted parallel or at a right angle to the machine table, making it ideal for straight-line machining operations that demand maximum rigidity.
Gibraltar Machine Vise: Single-Station Stationary Base 428-72682 Specifications
| Model | 428-72682 |
|---|---|
| Product Type | Single-Station Machine Vise |
| Jaw Width | 6 in. |
| Jaw Height | 1-19/32 in. (1.5938 in.) |
| Maximum Jaw Opening | 7-1/2 in. |
| Throat Depth | 1-19/32 in. |
| Operation Type | Manual |
| Orientation | Horizontal |
| Base Motion | Stationary |
| Number of Stations | 1 |
| Vise Material | Ductile Iron |
| Application | Machine Workholding |
| Overall Height | 4-5/8 in. |
| Precision | No |
| UNSPSC | 27112100 |
Gibraltar Machine Vise: Single-Station Stationary Base 428-72682 Features & Performance
- Heavy-duty ductile iron construction provides superior strength, durability, and resistance to deflection under heavy clamping loads.
- 6-inch wide jaws securely hold a wide variety of workpieces for milling, drilling, and machining applications.
- Large 7-1/2-inch jaw opening accommodates larger components while maintaining dependable clamping performance.
- Stationary base design maximizes rigidity for straight-surface machining where rotational positioning is not required.
- Horizontal vise configuration provides secure and accurate positioning throughout machining operations.
- Manual lead screw operation delivers smooth jaw movement and controlled clamping force for repeatable setups.
- Flexible mounting options allow the vise to be fastened parallel or at a right angle to the machine table for increased versatility.
- Single-station configuration offers excellent stability while maximizing usable work area.
- Ideal for production environments including manufacturing plants, fabrication shops, maintenance departments, and machine shops.
- Built for dependable daily operation where strong workholding and long service life are essential.
Why Choose the Gibraltar Machine Vise: Single-Station Stationary Base 428-72682
- Heavy-duty ductile iron construction for exceptional durability.
- Fixed-base design provides maximum rigidity during straight machining operations.
- Large 6-inch jaws with a 7-1/2-inch opening handle a wide range of workpiece sizes.
- Can be mounted parallel or perpendicular to the machine table for versatile setup options.
- Ideal for milling, drilling, fabrication, maintenance, and general machine shop work.
- Reliable manual operation designed for long-term industrial performance.
California Proposition 65 Warning: This product contains Nickel, a chemical known to the State of California to cause cancer. For more information, visit www.P65Warnings.ca.gov.
