Gibraltar Machine Vise: Single-Station, 4.0000" Jaw Width, 4" Jaw Opening, Swivel Base RHV/100 Applications
- Vertical and horizontal milling machine operations
- Drill press workholding for repetitive drilling applications
- General machining, fabrication, and maintenance shops
- Metalworking, prototype manufacturing, and repair facilities
- Clamping steel, aluminum, brass, cast iron, and other machinable materials
- Production environments requiring dependable manual workholding
- Educational machine shops and industrial training facilities
Designed for machinists who require strong, dependable clamping performance with the flexibility of a swivel base for accurate workpiece positioning.
Gibraltar Machine Vise: Single-Station, 4.0000" Jaw Width, 4" Jaw Opening, Swivel Base RHV/100 Specifications
| Manufacturer | Gibraltar |
|---|---|
| Model | RHV/100 |
| Operation | Manual |
| Number of Stations | Single Station |
| Jaw Width | 4.0000" (100 mm) |
| Jaw Height | 1.5000" (38 mm) |
| Maximum Jaw Opening | 4" |
| Throat Depth | 1-1/2" |
| Jaw Material | Steel |
| Vise Material | Cast Iron |
| Base Motion | Swivel |
| Orientation | Horizontal |
| Base Length | 9.5000" (242 mm) |
| Base Width | 7.00" |
| Base Height | 1.2600" (32 mm) |
| Overall Length | 13.6000" (346 mm) |
| Overall Width | 7.00" (178 mm) |
| Overall Height | 4-1/2" |
| Load Capacity | 2,700 lb |
| Precision Rated | No |
| Country of Origin | India |
| UNSPSC | 27112100 |
Gibraltar Machine Vise: Single-Station, 4.0000" Jaw Width, 4" Jaw Opening, Swivel Base RHV/100 Features & Construction
- Heavy-duty cast iron body provides excellent rigidity while minimizing vibration during machining operations.
- Hardened steel jaws deliver secure gripping performance and long service life under demanding shop conditions.
- 4-inch jaw width with 4-inch opening capacity accommodates a wide variety of workpiece sizes for everyday machining tasks.
- Swivel base design enables fast angular positioning, reducing setup time and improving machining flexibility.
- Single-station manual operation offers dependable mechanical clamping without requiring hydraulic or pneumatic systems.
- 2,700 lb clamping load capacity helps maintain secure workholding during drilling, milling, tapping, and light fabrication.
- Horizontal configuration integrates easily with milling machines, drill presses, and machining centers.
- Compact footprint allows installation on a wide range of machine tables while maximizing available workspace.
- Industrial-grade construction is suitable for maintenance departments, machine shops, fabrication facilities, and manufacturing environments.
Why Choose the Gibraltar Machine Vise: Single-Station, 4.0000" Jaw Width, 4" Jaw Opening, Swivel Base RHV/100
- Heavy-duty cast iron construction for long-term durability.
- Steel jaws provide dependable gripping performance.
- 4" jaw opening accommodates a wide range of workpieces.
- Swivel base enables fast and accurate angular positioning.
- 2,700 lb load capacity supports demanding machining operations.
- Ideal for milling, drilling, fabrication, maintenance, and general machine shop applications.
- Simple manual operation offers reliable workholding with minimal maintenance.
The Gibraltar Machine Vise: Single-Station, 4.0000" Jaw Width, 4" Jaw Opening, Swivel Base RHV/100 combines rugged cast iron construction, hardened steel jaws, and a versatile swivel base to deliver dependable workholding performance for everyday machining operations. Built for durability, stability, and ease of use, it is an excellent solution for professional machine shops, manufacturing facilities, maintenance departments, and industrial fabrication environments.
