Gibraltar Arbor Press 805-11305 Applications
- Bearing installation and removal
- Bushing and sleeve pressing
- Gear and pulley assembly
- Riveting and staking operations
- Broaching small keyways
- Machine shop repair and maintenance
- Production assembly work
- General industrial pressing applications
Ideal for shops requiring controlled manual pressing force for precision assembly, repair, fabrication, and maintenance operations.
Gibraltar Arbor Press 805-11305 Specifications
| Manufacturer | Gibraltar |
|---|---|
| Model | 805-11305 |
| Pressure Capacity | 3 Ton (3 t) |
| Leverage Style | Ratchet |
| Leverage Ratio | 20:1 |
| Ram Width / Diameter | 1-1/4" |
| Ram Stroke | 12" |
| Throat Depth | 6-1/4" |
| Maximum Work Height | 17-1/2" |
| Maximum Work Width / Diameter | 20-1/2" |
| Base Width | 8.5000" |
| Base Depth | 10.0000" |
| Table Width | 8.5000" |
| Table Length | 8.000" |
| Overall Height | 28.0000" |
| UNSPSC | 23251500 |
| Country of Origin | China |
Gibraltar Arbor Press 805-11305 Features & Performance
- 3-ton manual pressing capacity provides dependable force for assembly, repair, and fabrication tasks.
- 20:1 leverage ratio multiplies operator input to reduce effort while delivering controlled pressing power.
- Ratchet-style leverage mechanism allows efficient operation when working with larger or difficult components.
- 1-1/4-inch ram delivers stable, accurate pressing performance with excellent rigidity.
- 12-inch ram stroke provides extended travel for handling a wide range of component sizes.
- 6-1/4-inch throat depth accommodates larger workpieces and improves versatility.
- 17-1/2-inch maximum work height supports taller assemblies and pressing applications.
- Heavy-duty industrial construction is built for long service life in machine shops, maintenance departments, and manufacturing facilities.
Why Choose the Gibraltar Arbor Press 805-11305
- Powerful 3-ton manual pressing capacity.
- 20:1 leverage ratio minimizes operator effort.
- Long 12-inch stroke increases application flexibility.
- Deep throat design accommodates larger workpieces.
- Ideal for bearings, bushings, riveting, broaching, and assembly work.
- Built for dependable industrial performance and long-term durability.
The Gibraltar Arbor Press 805-11305 combines high mechanical advantage, heavy-duty construction, and versatile work capacity into a dependable manual pressing solution. Whether used for bearing installation, broaching, staking, riveting, or precision assembly, this arbor press delivers the controlled force, durability, and reliability required in professional industrial environments.
