Enco Floor Drill Press: Geared Head, 1-3/5" Swing ZX40H Applications
- General-purpose drilling in steel, cast iron, aluminum, and plastics.
- Machine shops and production manufacturing.
- Maintenance and repair departments.
- Prototype fabrication and custom machining.
- Fixture and tooling production.
- Industrial fabrication facilities.
- Educational and vocational machine shops.
- Heavy-duty drilling applications requiring geared head performance.
Ideal for industrial users requiring the durability, torque, and precision of a geared head floor drill press for continuous shop operation.
Enco Floor Drill Press: Geared Head, 1-3/5" Swing ZX40H Specifications
| Model | ZX40H |
|---|---|
| Stand Type | Floor |
| Drive Type | Geared Head |
| Voltage / Phase | 220 Volt / Single Phase |
| Frequency | 60 Hz |
| Spindle Speed Range | 90 – 1,970 RPM |
| Spindle Speed Control | Geared Head |
| Spindle Taper | R8 |
| Spindle Travel | 5" |
| Spindle to Table Distance | 18" |
| Drilling Capacity (Steel) | 1-1/4" |
| Drilling Capacity (Cast Iron) | 1-3/4" |
| Swing Capacity | 1-3/5" |
| Table Length | 31-1/2" |
| Overall Height | 80.75" |
| Overall Depth | 34-1/2" |
| UNSPSC Code | 23241801 |
| Country of Origin | China |
Enco Floor Drill Press: Geared Head, 1-3/5" Swing ZX40H Performance & Construction
- Heavy-duty geared head drive provides dependable torque transmission while reducing maintenance compared to traditional belt-driven systems.
- R8 spindle taper accepts a wide range of industry-standard drill chucks, collets, and precision tooling for expanded machining versatility.
- Spindle speed range from 90 to 1,970 RPM allows operators to match cutting speeds to different materials and drill sizes.
- Large drilling capacity handles holes up to 1-1/4" in steel and 1-3/4" in cast iron for demanding industrial applications.
- Five-inch spindle travel provides generous drilling depth while minimizing workpiece repositioning.
- Floor-standing design delivers excellent stability and rigidity for improved drilling accuracy and repeatable results.
- 31-1/2" work table offers ample space for securing vises, fixtures, and larger workpieces.
- 220V single-phase operation supplies reliable industrial performance without requiring three-phase electrical service.
- Rigid industrial construction minimizes vibration while improving hole quality and extending machine service life.
- Designed for continuous operation in machine shops, fabrication facilities, maintenance departments, and educational environments.
Why Choose the Enco Floor Drill Press: Geared Head, 1-3/5" Swing ZX40H
- Heavy-duty geared head transmission delivers consistent torque and reliability.
- Industry-standard R8 spindle supports a wide range of tooling.
- 90–1,970 RPM spindle speeds provide machining flexibility.
- Excellent drilling capacity for steel and cast iron applications.
- Rigid floor-standing construction improves precision and stability.
- Operates on convenient 220V single-phase power.
- Ideal for production machining, fabrication, maintenance, and industrial drilling operations.
The Enco Floor Drill Press: Geared Head, 1-3/5" Swing ZX40H combines industrial durability, geared head performance, and precision drilling capability into a dependable floor-mounted machine. With its R8 spindle, wide spindle speed range, heavy-duty construction, and generous drilling capacity, it provides a reliable solution for professional shops requiring consistent, high-quality drilling performance.
