TF 350 Highlights
- No fasteners needed: No screws or rivets, which saves cost and simplifies handling
- Strong, corrosion-resistant joints: Secure, resilient connection points in one operation
- 120 joining points per minute: Simple single-stroke activation with consistent strength and connection quality
- Coating-independent: Joining quality does not depend on whether surfaces are coated or uncoated
- Cordless option: 18V LiHD battery with Cordless Alliance System compatibility and brushless motor for independence from a power outlet
TF 350 Specifications
| Brand | TRUMPF |
|---|---|
| Model | TruTool TF 350 |
| Max Sheet Thickness, Steel 400 N/mm² | 3.5 mm |
| Max Sheet Thickness, Steel 600 N/mm² | 2.5 mm |
| Max Sheet Thickness, Aluminum up to 250 N/mm² | 4 mm |
| Minimum Sheet Thickness | 0.8 mm |
| Maximum Joining Force | 25 kN |
| Maximum Stroke Rate | 2 1/s |
| Minimum Edge Spacing | 8 mm - 58 mm |
| Maximum Flange Height (B) | 36 mm |
| Corded Motor | 1700 W, 8.3 kg, 411 x 358 mm |
| Cordless Motor | 18V LiHD battery, 8 kg incl. battery, 454 x 358 mm |
Standard Accessories Included with the TF 350
- Operator's manual
