Mrcool Advantage 5th Gen 9k BTU 115V Condenser A-09-HP-C-115D-O Applications
- Bedrooms, offices, and small living spaces up to 400 sq. ft.
- Single-zone ductless mini-split HVAC systems
- Home additions, garages, and workshops
- Energy-efficient HVAC upgrades and replacements
Ideal for smaller spaces requiring efficient, quiet, and eco-friendly heating and cooling performance.
Mrcool Advantage 5th Gen 9k BTU 115V Condenser A-09-HP-C-115D-O Specifications
| Brand | MRCOOL |
|---|---|
| Series | Advantage 5th Gen |
| Model | A-09-HP-C-115D-O |
| Unit Type | Mini-Split Condenser |
| Tonnage | 0.75 Ton |
| Cooling Capacity | 9,000 BTU |
| Heating Capacity | 10,000 BTU |
| SEER2 | 21.5 |
| EER2 | 12.5 |
| HSPF2-4 | 9.0 |
| Voltage | 115V |
| Phase | 1 |
| Frequency | 60 Hz |
| Max Fuse Breaker | 20 A |
| Min Circuit Ampacity | 18 A |
| Zone Capacity | 1 |
| Refrigerant Type | R-454B |
| Refrigerant Volume | 21.52 oz |
| Sound Level | 52.5 dBA |
| Compressor Type | Rotary (Inverter Driven) |
| Max Line Set Length | 82 ft |
| Liquid Line Size | 1/4" |
| Suction Line Size | 3/8" |
| Dimensions (W × H × D) | 30.12" × 21.85" × 11.93" |
| Net Weight | 56.66 lbs |
| Certifications | UL, CSA, ETL, AHRI, ENERGY STAR |
Mrcool Advantage 5th Gen 9k BTU 115V Condenser A-09-HP-C-115D-O Performance & Features
- High-Efficiency Performance with up to 21.5 SEER2 for reduced energy consumption and lower utility costs.
- Eco-Friendly R-454B Refrigerant delivers significantly lower global warming potential compared to older refrigerants.
- DC Inverter Technology provides precise temperature control and enhanced energy savings.
- Smart HVAC Compatibility supports control via mobile app, Amazon Alexa, and Google Assistant.
- Gold Fin® Coating enhances corrosion resistance for long-lasting outdoor durability.
- Quiet Operation engineered for low sound output while maintaining high performance.
- Advanced Safety Features including overload protection and refrigerant monitoring.
- Professional Installation Required ensures optimal system performance and longevity.
Why Choose the Mrcool Advantage 5th Gen 9k BTU 115V Condenser A-09-HP-C-115D-O
- High-efficiency heating and cooling for small spaces
- Environmentally friendly refrigerant with lower GWP
- Smart home integration for modern convenience
- Durable outdoor construction with corrosion protection
- Backed by MRCOOL® warranty for peace of mind
The Mrcool Advantage 5th Gen 9k BTU 115V Condenser A-09-HP-C-115D-O is a reliable, energy-efficient outdoor unit designed to deliver consistent performance, lower energy costs, and environmentally responsible comfort.
