Mrcool Advantage 5th Gen 18k BTU 230V Condenser A-18-HP-C-230D-O Applications
- Large bedrooms, living areas, and open-concept residential spaces up to 800 sq. ft.
- Single-zone ductless mini-split HVAC systems
- Home additions, garages, and workshops
- Energy-efficient HVAC upgrades and replacements
Ideal for larger spaces requiring powerful, efficient, and eco-friendly heating and cooling performance.
Mrcool Advantage 5th Gen 18k BTU 230V Condenser A-18-HP-C-230D-O Specifications
| Brand | MRCOOL |
|---|---|
| Series | Advantage 5th Gen |
| Model | A-18-HP-C-230D-O |
| Unit Type | Mini-Split Condenser |
| Tonnage | 1.5 Ton |
| Cooling Capacity | 18,000 BTU |
| Heating Capacity | 18,800 BTU |
| SEER2 | 19.2 |
| EER2 | 10.8 |
| HSPF2-4 | 9.6 |
| Voltage | 208–230V |
| Phase | 1 |
| Frequency | 60 Hz |
| Max Fuse Breaker | 20 A |
| Min Circuit Ampacity | 15 A |
| Zone Capacity | 1 |
| Refrigerant Type | R-454B |
| Refrigerant Volume | 40.57 oz |
| Sound Level | 56 dBA |
| Compressor Type | Rotary (DC Inverter) |
| Max Line Set Length | 98.4 ft |
| Liquid Line Size | 1/4" |
| Suction Line Size | 1/2" |
| Dimensions (W × H × D) | 31.69" × 21.81" × 12.99" |
| Net Weight | 72.31 lbs |
| Certifications | UL, CSA, ETL, AHRI |
Mrcool Advantage 5th Gen 18k BTU 230V Condenser A-18-HP-C-230D-O Performance & Features
- High-Capacity Performance designed for larger spaces with strong and consistent airflow.
- Eco-Friendly R-454B Refrigerant significantly lowers global warming potential compared to older refrigerants.
- DC Inverter Technology ensures precise temperature control and improved energy efficiency.
- Smart HVAC Compatibility allows control via mobile app, Amazon Alexa, and Google Assistant.
- Gold Fin® Coating enhances corrosion resistance for long-lasting outdoor durability.
- Quiet Operation engineered for reduced noise while maintaining powerful output.
- Advanced Safety Features including overload protection and refrigerant monitoring.
- Professional Installation Required ensures optimal system performance and longevity.
Why Choose the Mrcool Advantage 5th Gen 18k BTU 230V Condenser A-18-HP-C-230D-O
- High-capacity heating and cooling for larger residential spaces
- Energy-efficient operation with environmentally friendly refrigerant
- Smart home integration for modern convenience
- Durable outdoor construction with corrosion-resistant coating
- Backed by MRCOOL® warranty for peace of mind
The Mrcool Advantage 5th Gen 18k BTU 230V Condenser A-18-HP-C-230D-O delivers powerful, efficient, and intelligent climate control, making it an excellent solution for larger spaces requiring reliable year-round comfort.
