Kurt CNC Machines Vise: DX, Single-Station, 8.00" Jaw Width, 10.0" Jaw Opening, Stationary Base, Precision 81818304 Applications
- CNC milling centers requiring precise and repeatable workholding.
- High-production machining operations utilizing hydraulic clamping systems.
- Aerospace, automotive, defense, and precision manufacturing applications.
- Complex machining operations requiring rigid workpiece retention.
- Automated and semi-automated machining cells.
- Prototype development and high-accuracy component machining.
- Production environments seeking reduced setup time and improved consistency.
Designed specifically for CNC machining operations, this hydraulic DX Series vise delivers exceptional stability, repeatability, and workholding performance for demanding production environments.
Kurt CNC Machines Vise: DX, Single-Station, 8.00" Jaw Width, 10.0" Jaw Opening, Stationary Base, Precision 81818304 Specifications
| Product Type | CNC Machine Vise |
|---|---|
| Series | DX |
| Operation Type | Hydraulic |
| Number of Stations | 1 |
| Orientation | Horizontal |
| Base Motion Type | Stationary |
| Jaw Width | 8.00" |
| Maximum Jaw Opening Capacity | 10.0" |
| Jaw Height | 2.2000" |
| Throat Depth | 2.2000" |
| Jaw Style | Standard |
| Jaw Material | Steel |
| Vise Material | Steel |
| Base Length | 21.8700" |
| Base Width | 8.9300" |
| Base Height | 3.3100" |
| Overall Length | 27.4200" |
| Overall Width | 8.9300" |
| For Use With | CNC Machines |
| Precision Ground | Yes |
| Country of Origin | United States |
| UNSPSC Code | 27112100 |
Kurt CNC Machines Vise: DX, Single-Station, 8.00" Jaw Width, 10.0" Jaw Opening, Stationary Base, Precision 81818304 Features & Benefits
- Hydraulic actuation capability allows integration with a Kurt pump system for consistent and repeatable clamping performance.
- New body design with cast stationary jaw provides increased stability and reduced deflection during demanding machining operations.
- 8-inch jaw width delivers excellent support for larger workpieces and complex machining projects.
- 10-inch jaw opening capacity accommodates a wide range of part sizes and production requirements.
- Precision-ground construction helps maintain exceptional machining accuracy and repeatability.
- Horizontal orientation provides efficient loading, unloading, and workpiece accessibility.
- Stationary base design maximizes rigidity and minimizes movement under cutting forces.
- Steel vise and jaw construction ensures long-term durability and dependable performance.
- DX Series dimensional compatibility allows easy integration into existing DX Series machining setups and workflows.
- Single-station design offers dedicated precision workholding for demanding CNC applications.
- Hydraulic operation helps improve production efficiency by delivering consistent clamping force across repetitive machining cycles.
Kurt CNC Machines Vise: DX, Single-Station, 8.00" Jaw Width, 10.0" Jaw Opening, Stationary Base, Precision 81818304 Performance & Construction
- Engineered specifically for CNC machining environments where precision and repeatability are essential.
- Redesigned cast stationary jaw structure improves rigidity and reduces workpiece movement.
- Hydraulic clamping system supports consistent holding force across production runs.
- Large jaw opening capacity accommodates oversized and complex workpieces.
- Precision-ground surfaces support accurate setup alignment and machining consistency.
- Heavy-duty steel construction withstands demanding industrial manufacturing conditions.
- DX Series compatibility minimizes retrofit requirements and simplifies machine integration.
Why Choose the Kurt CNC Machines Vise: DX, Single-Station, 8.00" Jaw Width, 10.0" Jaw Opening, Stationary Base, Precision 81818304
- Hydraulic operation delivers repeatable and efficient clamping performance.
- Cast stationary jaw design improves stability and reduces deflection.
- Large 8-inch jaw width and 10-inch opening accommodate demanding workholding applications.
- DX Series dimensional compatibility simplifies integration into existing workflows.
- Precision-ground construction supports superior machining accuracy.
- Made in the USA and engineered for professional CNC machining environments.
The Kurt CNC Machines Vise: DX, Single-Station, 8.00" Jaw Width, 10.0" Jaw Opening, Stationary Base, Precision 81818304 combines hydraulic workholding technology, enhanced structural rigidity, and proven DX Series compatibility to deliver exceptional performance, accuracy, and productivity in advanced CNC machining applications.
