Kurt CNC Machines Vise: DX, Single-Station, 6.00" Jaw Width, 9.0" Jaw Opening, Stationary Base, Precision 67155739 Applications
- CNC machining centers requiring automated workholding.
- Production manufacturing environments utilizing pneumatic clamping.
- Robotic machining cells and automated machine tending systems.
- PLC-controlled machining operations.
- High-volume machining applications requiring repeatability.
- Precision milling, drilling, and metalworking operations.
- Lights-out manufacturing and unattended machining environments.
- Industrial facilities seeking improved productivity and reduced cycle times.
The DX Series pneumatic vise is designed to improve production efficiency by utilizing shop air for rapid clamping operations while maintaining the precision and rigidity required for CNC machining applications.
Kurt CNC Machines Vise: DX, Single-Station, 6.00" Jaw Width, 9.0" Jaw Opening, Stationary Base, Precision 67155739 Specifications
| Series | DX |
|---|---|
| Jaw Width | 6.00" |
| Jaw Height | 1.7350" |
| Maximum Jaw Opening | 9.0" |
| Jaw Style | Standard |
| Jaw Material | Steel |
| Throat Depth | 1.7350" |
| Operation Type | Air (Pneumatic) |
| Orientation | Horizontal |
| Number of Stations | 1 |
| Base Motion Type | Stationary |
| Base Length | 24.1700" |
| Base Width | 7.3910" |
| Base Height | 2.8750" |
| Overall Length | 24.1700" |
| Overall Width | 7.3910" |
| Vise Material | Steel |
| Precision Rated | Yes |
| Country of Origin | United States |
| UNSPSC Code | 27112100 |
Kurt CNC Machines Vise: DX, Single-Station, 6.00" Jaw Width, 9.0" Jaw Opening, Stationary Base, Precision 67155739 Features & Benefits
- Pneumatic Vise Actuation operates using standard shop air to improve clamping speed and production efficiency.
- 1/4-Inch Pneumatic Stroke provides fast and consistent jaw movement during loading and unloading operations.
- 6-Inch Jaw Width with 9-Inch Opening Capacity accommodates a wide variety of workpiece sizes and machining applications.
- Manual and Remote Operation Capability allows operators to actuate the vise using the built-in lever or optional remote switching systems.
- Automation-Ready Design can be fully automated through the addition of a solenoid and DIN cable connected to a machine tool controller, PLC, or robotic system.
- DX Vise Body Construction features a cast stationary jaw design that provides greater stability and reduced deflection under load.
- Lower-Profile Air Unit helps maximize machine envelope utilization while maintaining reliable pneumatic performance.
- Precision-Rated Performance supports repeatable workholding and consistent machining accuracy.
- Rigid Steel Construction delivers durability and long service life in demanding CNC manufacturing environments.
- Pneumatic Screw Kit Upgrade Available for newer DX vise models seeking enhanced pneumatic functionality.
Why Choose the Kurt CNC Machines Vise: DX, Single-Station, 6.00" Jaw Width, 9.0" Jaw Opening, Stationary Base, Precision 67155739
- Increases productivity through rapid pneumatic clamping.
- Supports automation, robotics, PLC integration, and CNC control systems.
- Reduces setup time while improving repeatability.
- DX Series construction delivers superior stability and reduced deflection.
- Flexible operation through manual, remote, or fully automated actuation.
- Precision-rated design supports demanding production machining applications.
- Manufactured in the USA for dependable quality and performance.
The Kurt CNC Machines Vise: DX, Single-Station, 6.00" Jaw Width, 9.0" Jaw Opening, Stationary Base, Precision 67155739 combines pneumatic efficiency, automation readiness, and the proven rigidity of Kurt's DX platform to deliver high-performance workholding for modern CNC machining operations. Ideal for production facilities seeking increased throughput, repeatability, and manufacturing efficiency.
