Kurt 1-1/8" Aluminum Bronze Hex, 1/2-13 Stud Thread, Symmetrical Hex Clamp 09509837 Applications
- Fixture plate and modular fixturing systems.
- CNC machining centers requiring secure part retention.
- Production manufacturing operations utilizing repeatable workholding setups.
- Toolroom and machine shop fixture construction.
- Precision machining of matching or symmetrical components.
- Assembly fixtures and inspection fixtures.
- Custom workholding applications requiring compact clamping solutions.
Ideal for fixtures containing matching or mirrored components, the symmetrical hex clamp design provides consistent clamping pressure and reliable positioning accuracy.
Kurt 1-1/8" Aluminum Bronze Hex, 1/2-13 Stud Thread, Symmetrical Hex Clamp 09509837 Specifications
| Product Type | Symmetrical Hex Clamp Set |
|---|---|
| Hex Type | Symmetrical |
| Hex Size | 1-1/8" |
| Hex Height | 0.3750" (3/8") |
| Hex Head Material | Aluminum Bronze |
| Stud Material | Alloy Steel |
| Stud Thread Size | 1/2-13 |
| Thread Length | 1.2500" |
| Holding Force | 2,600 lb |
| Torque Rating | 83 ft/lb |
| Number of Clamps | 6 |
| UNSPSC Code | 27112800 |
Kurt 1-1/8" Aluminum Bronze Hex, 1/2-13 Stud Thread, Symmetrical Hex Clamp 09509837 Features & Benefits
- Symmetrical hex clamp design provides balanced clamping force for applications involving matching or mirrored components.
- 2,600 lb holding force delivers reliable workpiece retention during machining and fixture operations.
- Aluminum bronze clamp heads offer excellent durability, corrosion resistance, and long service life.
- Alloy steel studs provide exceptional strength and dependable fastening performance.
- 1/2-13 thread size ensures compatibility with common fixture and workholding systems.
- 1.25-inch thread length provides secure engagement and installation flexibility.
- 83 ft/lb torque capacity supports strong and repeatable clamping performance.
- Compact 3/8-inch clamp height minimizes interference while maximizing workspace accessibility.
- Six-clamp set provides a complete solution for multi-point fixturing applications.
- Designed for precision workholding to improve setup consistency and manufacturing efficiency.
- Symmetrical hex clamps are used with parts that have similar matching components, making them ideal for fixture systems requiring balanced clamping and repeatable positioning.
Kurt 1-1/8" Aluminum Bronze Hex, 1/2-13 Stud Thread, Symmetrical Hex Clamp 09509837 Performance & Construction
- Engineered for demanding machining and fixture applications.
- High-strength alloy steel studs provide dependable load-bearing capability.
- Aluminum bronze construction delivers excellent wear resistance and durability.
- Compact design maximizes usable workspace around the fixture.
- Precision-machined components ensure repeatable clamping performance.
- Balanced clamping action helps maintain part alignment and positioning accuracy.
- Designed to withstand repeated setup cycles in industrial manufacturing environments.
Why Choose the Kurt 1-1/8" Aluminum Bronze Hex, 1/2-13 Stud Thread, Symmetrical Hex Clamp 09509837
- Provides up to 2,600 pounds of dependable holding force.
- Symmetrical design is ideal for matching component applications.
- Durable aluminum bronze and alloy steel construction.
- Compact profile improves fixture accessibility and workspace utilization.
- Complete six-clamp set supports versatile fixturing requirements.
- Engineered for precision machining, manufacturing, and workholding applications.
The Kurt 1-1/8" Aluminum Bronze Hex, 1/2-13 Stud Thread, Symmetrical Hex Clamp 09509837 combines high holding power, durable materials, and precision fixturing performance to deliver a reliable workholding solution for demanding industrial and machining environments.
