Baileigh Variable-Speed Welding Positioner (WP-750) 1008397 Applications
- Structural steel and fabrication welding projects.
- Pipe, tube, and cylindrical component welding.
- Manufacturing and production welding operations.
- Automotive, motorsports, and custom fabrication applications.
- Pressure vessel and tank fabrication.
- Prototype development and specialty welding projects.
- Rotational welding of assemblies requiring continuous weld beads.
- Improving weld access on complex and multi-angle components.
The Baileigh Variable-Speed Welding Positioner (WP-750) 1008397 helps fabricators achieve more consistent weld quality while reducing repositioning time and operator strain.
Baileigh Variable-Speed Welding Positioner (WP-750) 1008397 Specifications
| Model | WP-750 |
|---|---|
| Product Type | Welding Positioner |
| Input Power | 110V Single Phase |
| Motor Power | 1/8 HP |
| Turntable Diameter | 13 in. |
| Vertical Capacity | 770 lbs. |
| Horizontal Capacity | 385 lbs. |
| Rotation Speed | 0.3 – 4 RPM Variable |
| Motor Speed | 0 – 4 RPM |
| Tilt Range | 0° – 90° |
| Welding Current Capacity | 300 Amps Continuous |
| Maximum Burst Current | 500 Amps |
| Net Weight | 175 lbs. |
| Gross Weight | 175 lbs. |
| UPC | 731325420593 |
| Warranty | 1 Year |
| California Prop 65 | Cancer and Reproductive Harm |
Baileigh Variable-Speed Welding Positioner (WP-750) 1008397 Performance & Construction
- 770 lb Vertical Capacity supports medium-sized weldments while maintaining smooth and stable rotational performance.
- 385 lb Horizontal Capacity allows reliable positioning of components mounted in horizontal configurations.
- 13-Inch Precision Turntable provides a versatile mounting platform suitable for a wide range of fabrication projects.
- Variable-Speed Rotation adjusts from approximately 0.3 to 4 RPM, allowing operators to precisely match rotation speed to welding requirements.
- Reversible Rotation Control enables clockwise or counterclockwise operation for greater welding flexibility and improved accessibility.
- 0° to 90° Tilting Range positions workpieces at optimal angles to improve weld quality and operator comfort.
- Foot Pedal Operation allows hands-free speed and positioning control, helping welders maintain focus on weld quality.
- 110V Power Requirement makes installation simple in most fabrication shops and manufacturing facilities.
- Heavy-Duty Steel Construction delivers durability, stability, and long service life in demanding industrial environments.
- 300 Amp Continuous Capacity supports a wide variety of welding processes and production applications.
- 500 Amp Burst Current Rating provides additional capability for higher-demand welding operations.
- Compact Industrial Footprint maximizes productivity without consuming excessive shop floor space.
- Baileigh Warranty and Technical Support includes a 1-year parts warranty and lifetime technical support.
Why Choose the Baileigh Variable-Speed Welding Positioner (WP-750) 1008397
- Supports up to 770 lbs. in vertical positioning applications.
- Variable-speed control improves weld consistency and finish quality.
- 13-inch turntable accommodates a wide range of workpiece sizes.
- Tilts from 0° to 90° for enhanced weld accessibility.
- Foot pedal control enables efficient hands-free operation.
- Reversible rotation expands setup flexibility.
- Operates on standard 110V shop power.
- Heavy-duty construction built for fabrication and production environments.
- Backed by Baileigh's 1-year warranty and lifetime technical support.
The Baileigh Variable-Speed Welding Positioner (WP-750) 1008397 is an ideal solution for fabrication professionals seeking improved weld quality, faster production times, and superior workpiece control. With variable-speed rotation, a tilting turntable, foot pedal operation, and substantial load capacity, this welding positioner delivers professional performance for demanding welding applications.
