Safetyspeed H6 Panel Saw with 74″ Cutting Height Applications
- Cabinet and furniture manufacturing operations
- Millwork and woodworking shops processing large panels
- Plastic, composite, and aluminum panel cutting
- Workshops handling oversized sheet goods up to 10′ × 6′
- Small to mid-sized production environments requiring precision cuts
Perfect for shops needing increased vertical cutting capacity while maintaining a compact machine footprint.
Safetyspeed H6 Panel Saw with 74″ Cutting Height Specifications
| Model | H6 |
|---|---|
| Maximum Crosscut | 74″ / 1850 mm |
| Maximum Rip Cut | Unlimited |
| Maximum Cut Depth | 1.75″ / 45 mm |
| Cut Accuracy | 1/32″ / 0.8 mm (straight & square) |
| Frame Length | 120″ / 3050 mm |
| Machine Dimensions | 120″ × 11″ × 95″ |
| Weight | 359 lbs |
| Motor | 3.25 HP, 15A, 120V (220V option available) |
| Motor Manufacturer | Milwaukee Tool |
| Saw Blade Diameter | 8″ / 210 mm |
| Saw Blade Bore | 5/8″ |
| Rollers | 14 Injection-Molded Rollers |
| Guide Tubes | Zinc Plated 1.75″ Steel |
| Daily Usage | 1–3 Hours |
| Country of Origin | USA |
| Certifications | TUV Certified to UL/CSA Standards |
Safetyspeed H6 Panel Saw with 74″ Cutting Height Features & Performance
- 74″ vertical crosscut capacity allows cutting of large panels up to 10′ × 6′ with ease.
- Compact 30 sq. ft. footprint maximizes workspace efficiency in smaller shops.
- One-piece welded steel frame ensures long-term durability and structural rigidity.
- Low maintenance bearing and guide system supports precision tolerances from .030″ to .005″.
- 4 Nylatron roller bearing systems provide smooth, accurate carriage movement.
- Quick change from vertical to horizontal cutting increases versatility and workflow efficiency.
- Built-in vertical and horizontal rulers enable fast, accurate measurements directly on the machine.
- Spring-loaded counterbalance system ensures controlled and effortless saw movement.
- Injection-molded rollers with maintenance-free bearings allow smooth material handling.
- Integrated dust collection bonnet and dust port supports connection to external vacuum systems.
- Thin material pressure guard secures lightweight materials during cutting.
- Heavily guarded saw blade enhances operator safety by minimizing accidental contact.
- Industrial-grade Milwaukee motor delivers reliable cutting power up to 1.75″ material thickness.
- Simple controls provide easy operation across various skill levels and shop environments.
Safetyspeed H6 Panel Saw with 74″ Cutting Height Cutting Capabilities
- Handles full-size panels with single-operator efficiency
- Supports both vertical and horizontal cutting configurations
- Optional saw and router combination capability for expanded functionality
- Capable of cutting materials up to 1.75″ thick with precision accuracy
- Unlimited rip capacity for flexible material sizing
Why Choose the Safetyspeed H6 Panel Saw with 74″ Cutting Height
- Largest crosscut capacity in its class for handling oversized panels
- Space-saving vertical design with only 30 sq. ft. footprint
- High precision cutting accuracy of 1/32″ straight and square
- Durable, low-maintenance construction for long-term reliability
- Ideal balance of performance, size, and affordability for growing shops
The Safetyspeed H6 Panel Saw with 74″ Cutting Height is the perfect solution for shops that need expanded cutting capacity, precision performance, and efficient use of floor space—all in one powerful vertical panel saw.
