Castaly Auto 24" Feed Through Spray Booth 6 Guns TS-24ATAM Applications
- Profile strip finishing in a single continuous pass
- Two-edge or four-edge panel spraying operations
- Cabinet frame and molding production lines
- Automated woodworking finishing facilities
- Medium to high-volume coating production environments
Engineered for fast, automated spraying with improved material efficiency and reduced manual handling.
Castaly Auto 24" Feed Through Spray Booth 6 Guns TS-24ATAM Specifications
| Model | TS-24ATAM |
|---|---|
| Working Width | 24" |
| Maximum Working Thickness | 3-1/2" |
| Working Length | Infinite (Feed Through) |
| Maximum Working Width (Internal) | 21-1/2" |
| Feed Speed | 34 ~ 96 FPM |
| Spray Guns | 4 PCS (Standard) |
| Pneumatic Paint Pump | 1 Set |
| Collection Trays | 2 PCS |
| Main Motor | 5 HP |
| Machine Size (L × W × H) | 138" × 73" × 78" |
| Net Weight | 3,980 LBS |
Castaly Auto 24" Feed Through Spray Booth 6 Guns TS-24ATAM Control & Performance
- PLC control system provides easy operation and flexible parameter setup.
- High-speed spray processing finishes profile strips and panel edges in one pass.
- Photocell sensor-controlled spray guns automatically regulate spray timing to reduce overspray and save coating material.
- Individual spray volume adjustment for precise paint control on each gun.
- Variable feed speed control (34–96 FPM) ensures optimal finish quality for different materials.
- Two paint collection trays allow unused paint recovery for reuse and cost efficiency.
- Powerful collection fan with filtration system purifies exhaust air within a fully enclosed cabinet.
- Heavy-duty sheet metal enclosure frame ensures structural stability and pollution containment.
- See-through cabinet windows provide safe monitoring of internal spray operations.
Castaly Auto 24" Feed Through Spray Booth 6 Guns TS-24ATAM Equipment Configuration
- Standard equipment: One pneumatic paint pump and four spray guns.
- Expandable configuration: Additional spray guns available as optional equipment (up to 6-gun setup).
- Continuous feed-through design integrates easily into automated production lines.
Expandable multi-gun configuration allows customization based on production capacity and finishing requirements.
Why Choose the Castaly Auto 24" Feed Through Spray Booth 6 Guns TS-24ATAM
- Automated PLC-controlled system for consistent finishing performance.
- Material-saving photocell spray control technology.
- Adjustable feed speed for optimized surface results.
- Fully enclosed structure with air purification for cleaner operation.
- Durable industrial construction for long-term production use.
The Castaly Auto 24" Feed Through Spray Booth 6 Guns TS-24ATAM delivers efficient automated finishing, precise spray control, and industrial-grade enclosure design—making it an ideal solution for professional profile and panel edge coating operations.
